Towable Passenger Boarding Steps

Towable Passenger Boarding Steps Technical parameters

Overall dimensions (L×W×H): 7450×2500×3600mm

Lift height range of passenger lift ： 2150~4800mm

Upper platform size: 4150mm*2200mm

Ladder size: 292mm*1500mm*192mm

Stroke of movable platform: 0-400mm

Maximum angle between the ladder body and the level ： 37.5°.

Minimum ground clearance ： 160mm

Outer diameter of channel circle ： 16100mm

Overall quality ： 7550KG

Carrying capacity: 88 persons

Front axle load capacity: 2590kg

Rear axle load capacity ： 4960kg

Maximum speed: 80

Drive motor power ： 60kw

Total voltage: 618.24V

Total energy storage capacity ： Li-FePO4 battery 106.95kwh

Temperature range ： -35～65

Battery energy density: 153.84Wh/kg
