Vehicle length × width × height (mm): 8200 × 2150 × 1920
Diameter of channel circle(mm): 15400
Departure angle(°): 31
Approach angle(°): 10.5
Longitudinal passing angle(°): 20
Overall mass(kg): 3500
Minimum Ground Clearance(mm): 170
Maximum speed(km/h): 35
Mileage km: 316
Range (large airports) Km+t: 251+372
Range (medium-sized airports) Km+t: 251+372
Range (large airports) Km+t: 250+375
Carrying capacity of conveyor belt (kg/m) ： 135
Lifting range of front end of conveyor belt mm: 1160-4380
Conveyor belt rear lifting range mm ： 380-1560
Conveyor width mm ： 700
Conveyor speed m/s : 0.16-0.5
Temperature range(°): -35-65
Total voltage V: 309.12
Total energy storage capacity Kwh: 70.48
Rated power/speed kw/r/min ： 30/3000
